ADI精密模數轉換器
發布時間：2021-06-11 17:05:40 瀏覽：1489
ADI提供無可挑剔的精密模數轉換器組合。ADI的精密ADC系列是行業內技術領先的產品，提供交流和直流安全性能、功能損耗、速率和規格尺寸，分辨率從8位到32位。ADI支持便捷性，更重視幫助ADI客戶在組件級和信號鏈級快速地實現最終設計方案目標。從一整套專用工具中進行挑選，以優化從挑選到原型生產制作的全過程。
ADI精密模數轉換器提供多種多樣架構：
SAR逐次突破ADC；
Σ-Δ調制器；
隔離式ADC；
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
*詳情咨詢更多型號請聯系我們的銷售工程師！
產品型號 | Channels | Resolution | Sample Rate (max) | ADC SNR in dBFS (typ) | INL in LSB (typ) | Power (typ) |
|
| bits | SPS | dBFS | LSBs | W |
ADAQ4001 | 1 | 16 | 2M | 95.5 | 0.5 | 51.6m |
AD4695 | 16 | 16 | 500k | 93 | 0.4 | 4m |
AD4696 | 16 | 16 | 1M | 93 | 0.4 | 8m |
AD7606C-16 | 8 | 16 | 1M | 92 | 0.5 | 47m |
ADAQ23875 | 1 | 16 | 15M | 89.5 | 0.6 | 143 |
AD4680 | 2 | 16 | 1M | 92.5 | 0.7 | 29.4m |
AD4681 | 2 | 16 | 500k | 92.5 | 0.7 | 18.7m |
AD4682 | 2 | 16 | 1M | 87.5 | 1 | 29m |
AD4683 | 2 | 16 | 500k | 87.5 | 1 | 29.4m |
AD7606C-18 | 8 | 18 | 1M | 93 | 2 | 245m |
ADAQ4003 | 1 | 18 | 2M | 100 | 0.4 | 57.4m |
ADUM7704 | 1 | 16 | 78.1k |
| 2 | 130m |
AD4114 | 16 | 24 | 31.25k |
|
| 19.5m |
AD4115 | 16 | 24 | 125k |
|
| 52m |
AD7383 | 2 | 16 | 4M | 86.1 | 1 | 87m |
AD7384 | 2 | 14 | 4M | 84.1 | 0.4 | 84m |
ADUM7702 | 1 | 16 | 78.1k |
| 2 | 47.6m |
AD7380-4 | 4 | 16 | 4M |
|
|
|
ADAQ7768-1 | 1 | 24 | 1.024M | 105.3 |
| 223m |
ADAQ23876 | 1 | 16 | 15M | 89.5 | 0.6 | 143 |
ADAQ23878 | 1 | 18 | 15M | 89.5 | 0.6 | 143 |
AD7134 | 4 | 24 | 1.5M | 107 |
| 504m |
AD4021 | 1 | 20 | 1M | 100.5 | 1 | 8.3m |
AD4022 | 1 | 20 | 500k | 100.5 | 1 | 4.5m |
ADE1201 | 1 | 8 | 100k |
| 25 | 14.19m |
ADE1202 | 2 | 8 | 100k |
| 25 | 14.19m |
AD7386 | 4 | 16 | 4M | 87.5 | 1.5 | 83m |
AD7387 | 4 | 14 | 4M | 84 | 0.5 | 81m |
AD7388 | 4 | 12 | 4M | 73.8 | 0.2 | 80m |
AD74412R | 4 | 16 | 4.8k |
|
|
|
AD74413R | 4 | 16 | 4.8k |
|
|
|
AD7606B | 8 | 16 | 800k | 89.5 | 1.16 | 40m |
ADUM7703 | 1 | 16 | 78.1k |
| 2 | 46m |
AD4110-1 | 1 | 24 | 125k |
|
| 200m |
AD7380 | 2 | 16 | 4M | 92.5 | 0.75 | 83m |
AD7381 | 2 | 14 | 4M | 85.4 | 0.3 | 83m |
ADUM7701 | 1 | 16 | 78.1k |
| 2 | 46m |
AD4111 | 16 | 24 | 31.25k |
|
| 19.5m |
AD4112 | 16 | 24 | 31.25k |
|
| 19.5m |
AD7768-1 | 1 | 24 | 1.024M | 108 |
| 26.4m |
AD4002 | 1 | 18 | 2M | 95 | 0.8 | 14m |
AD4006 | 1 | 18 | 1M | 95 | 0.8 | 7m |
AD4010 | 1 | 18 | 500k | 95 | 0.8 | 3.5m |
LTC2353-16 | 2 | 16 | 550k | 94.2 | 0.3 | 162m |
AD4008 | 1 | 16 | 500k | 93 | 0.2 | 2m |
LTC2357-16 | 4 | 16 | 350k | 94.2 | 0.3 | 175m |
LTC2357-18 | 4 | 18 | 350k | 96.4 | 1 | 174m |
AD4007 | 1 | 18 | 1M | 100.5 | 0.4 | 8m |
AD4011 | 1 | 18 | 500k | 100.5 | 0.4 | 4m |
AD4020 | 1 | 20 | 1.8M | 100.5 | 1 | 15m |
AD7616-P | 16 | 16 | 1M | 90.5 | 1 | 230m |
AD7617 | 16 | 14 | 1M | 85 | 0.3 | 230m |
AD7771 | 8 | 24 | 128k | 95 | 1.5 | 133m |
LTC2324-12 | 4 | 12 | 2M | 78.5 | 0 | 102m |
LTC2324-14 | 4 | 14 | 2M | 82 | 1 | 102m |
LTC2324-16 | 4 | 16 | 2M | 82 | 2 | 102m |
LTC2325-12 | 4 | 12 | 5M | 77 | 0.5 | 102m |
LTC2325-14 | 4 | 14 | 5M | 82 | 1 | 102m |
LTC2333-16 | 8 | 16 | 800k | 94.2 | 0.3 | 268m |
LTC2333-18 | 8 | 18 | 800k | 96.4 | 0.75 | 268m |
AD4004 | 1 | 16 | 1M | 93 | 0.2 | 7m |
AD4005 | 1 | 16 | 1M | 96.2 | 0.2 | 8m |
ADAQ7980 | 1 | 16 | 1000k | 91.5 | 0.5 | 21m |
ADAQ7988 | 1 | 16 | 500k | 91.5 | 0.5 | 16.5m |
LTC2320-12 | 8 | 12 | 1.5M | 77 | 0.25 | 102m |
LTC2320-14 | 8 | 14 | 1.5M | 81 | 1 | 102m |
LTC2325-16 | 4 | 16 | 5M | 82 | 2 | 102m |
LTC2358-18 | 8 | 18 | 200k | 96.4 | 1 | 219m |
LTC2500-32 | 1 | 32 | 1M | 148 | 2147 | 24m |
AD4001 | 1 | 16 | 2M | 96.2 | 0.2 | 16m |
LTC2353-18 | 2 | 18 | 550k | 96.4 | 1 | 187m |
LTC2358-16 | 8 | 16 | 200k | 94.2 | 0.3 | 219m |
AD4000 | 1 | 16 | 2M | 93 | 0.2 | 14m |
AD4003 | 1 | 18 | 2M | 100.5 | 0.4 | 16m |
AD7605-4 | 4 | 16 | 300k | 90 | 0.5 | 71m |
AD7616 | 16 | 16 | 1M | 90.5 | 1 | 230m |
LTC2310-14 | 1 | 14 | 2M | 82 | 0.8 | 25m |
LTC2310-16 | 1 | 16 | 2M | 82 | 3 | 30m |
LTC2311-12 | 1 | 12 | 5M | 73 | 0.25 | 30m |
LTC2344-16 | 4 | 16 | 400k | 93.4 | 0.3 | 81m |
LTC2344-18 | 4 | 18 | 400k | 95 | 1.5 | 81m |
LTC2508-32 | 1 | 32 | 1M | 145 | 2147 | 24m |
RT2378-20 | 1 | 20 | 1M | 104 | 0.5 | 21m |
