ADI精密運算放大器 (Vos<1mV且TCVos<2uV/C)
發布時間：2021-10-22 17:01:30 瀏覽：1914
ADI精密運算放大器能夠為需要傳統化的調節零漂移放大器技術應用的設計工作人員提供行業內較先進的支持。ADI精密運算放大器有利于維持輸入信號的直流信息精準度，同時具備較低失調電壓(VOS<1mV)和較低溫漂特性(TCVOS<2μV/°C)。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.sengliu.cn/brand/25.html
或聯系ADI的銷售工程師： 0755-83642657 QQ: 2295048674
產品型號 | # of Amps | Vos (max) | Vos TC (typ) | GBP (typ) | Slew Rate (typ) | VNoise Density (typ) | 0.1 to 10 Hz VNoise (typ) | Iq/Amp (typ) | Vs span (min) | Vs span (max) |
|
| V | V/°C | Hz | V/us | V/rtHz | V p-p | A | V | V |
ADA4097-1 | 1 | 60μ | 100n | 130k | 100m | 53n | 1μ | 32.5μ | 3 | 50 |
ADA4098-1 | 1 | 15μ | 100n | 1.05M | 400m | 18n | 400n | 162.5μ | 3 | 55 |
ADA4099-1 | 1 | 25μ | 100n | 8M | 4 | 7n | 150n | 1.5m | 3.15 | 55 |
LTC2068 | 4 | 5μ |
| 100k | 17.5m | 80n | 1.7μ | 7.5μ | 1.7 | 5.25 |
ADA4523-1 | 1 | 5μ |
| 5M | 1.85 | 4.2n | 88n | 4.5m | 4.5 | 36 |
LTC2065 | 4 | 5μ |
| 20k | 3.5m | 220n | 4.6μ | 1.4μ | 1.7 | 5.25 |
LTC6226 | 1 | 95μ | 400n | 420M | 180 | 1n | 770n | 5.5m | 2.8 | 11.75 |
LTC6227 | 2 | 95μ | 400n | 420M | 180 | 1n | 770n | 5.5m | 2.8 | 11.75 |
LTC6229 | 2 | 95μ | 400n | 890M | 500 | 880p | 940n | 16m | 2.8 | 11.75 |
ADA4625-2 | 2 | 100μ | 200n | 18M | 48 | 3.3n | 150n | 4m | 5 | 36 |
LTC6228 | 1 | 95μ | 400n | 890M | 500 | 880p | 940n | 16m | 2.8 | 11.75 |
ADHV4702-1 | 1 | 1m | 250n | 10M | 74 | 8n |
| 3m | 24 | 220 |
LTC2050HV | 1 | 3μ | 10n | 3M | 2 |
| 1.5μ | 800μ | 2.7 | 11 |
LTC2064 | 2 | 5μ |
| 20k | 3.5m | 220n | 4.6μ | 1.4μ | 1.7 | 5.25 |
LTC2067 | 2 | 5μ |
| 100k | 17.5m | 80n | 1.7μ | 7.5μ | 1.7 | 5.25 |
LTC2058 | 2 | 5μ | 25n | 2.5M | 1.6 | 9n | 200n | 950μ | 4.75 | 36 |
ADA4625-1 | 1 | 80μ | 200n | 18M | 48 | 3.3n | 150n | 4m | 5 | 36 |
ADA4622-4 | 4 | 350μ | 2μ | 8M | 23 | 12.5n | 750n | 665μ | 5 | 30 |
ADA4622-1 | 1 | 350μ | 2μ | 8M | 23 | 12.5n | 750n | 715μ | 5 | 30 |
LTC2063 | 1 | 5μ |
| 20k | 3.5m | 220n | 4.6μ | 1.4μ | 1.7 | 5.25 |
LTC6258 | 1 | 400μ | 1.5μ | 1.3M | 240m | 38n | 2μ | 20μ | 1.8 | 5.25 |
LTC6259 | 2 | 400μ | 1.5μ | 1.3M | 240m | 38n | 2μ | 20μ | 1.8 | 5.25 |
LTC6260 | 4 | 400μ | 1.5μ | 1.3M | 240m | 38n | 2μ | 20μ | 1.8 | 5.25 |
LTC6261 | 1 | 400μ | 400n | 30M | 7 | 13n | 1.25μ | 245μ | 1.8 | 5.25 |
LTC6262 | 2 | 400μ | 400n | 30M | 7 | 13n | 1.25μ | 245μ | 1.8 | 5.25 |
LTC6263 | 4 | 400μ | 400n | 30M | 7 | 13n | 1.25μ | 245μ | 1.8 | 5.25 |
LTC2066 | 1 | 5μ |
| 100k | 17.5m | 80n | 1.7μ | 7.5μ | 1.7 | 5.25 |
LT6018 | 1 | 50μ | 200n | 15M | 30 | 1.2n | 30n | 7.2m | 8 | 33 |
ADA4522-1 | 1 | 5μ | 2.5n | 2.7M | 1.7 | 5.8n | 117n | 840μ | 4.5 | 55 |
ADA4077-2S | 2 | 35μ |
| 3.9M |
|
|
|
| 5 | 30 |
ADA4522-4 | 4 | 5μ | 2.5n | 2.7M | 1.7 | 5.8n | 117n | 830μ | 4.5 | 55 |
ADA4530-1 | 1 | 40μ | 0.13μ | 2M | 1.4 | 14n | 4μ | 900μ | 4.5 | 16 |
ADA4622-2 | 2 | 350μ | 2μ | 8M | 23 | 12.5n | 0.75μ | 665μ | 5 | 30 |
ADA4806-1 | 1 | 125μ | 200n | 30M | 160 | 5.2n |
| 570μ | 3 | 10 |
ADA4807-4 | 4 | 175μ | 700n | 200M | 225 | 3.3n | 160n | 1m | 2.7 | 11 |
ADA4522-2 | 2 | 5μ | 4n | 2.7M | 1.7 | 5.8n | 117n | 830μ | 4.5 | 55 |
ADA4084-2S | 2 | 100μ |
|
|
|
|
|
| 3 | 30 |
ADA4177-1 | 1 | 60μ | 1μ | 3.5M | 1.5 | 8n | 175n | 500μ | 10 | 30 |
ADA4350 | 1 | 80μ | 100n | 175M | 100 | 5n |
| 8.5m | 3.3 | 12 |
ADA4807-2 | 2 | 125μ | 700n | 200M | 225 | 3.3n | 160n | 1m | 2.7 | 11 |
LT6023 | 2 | 30μ | 500n | 40k | 1.45 | 132n |
| 18μ | 3 | 30 |
LT6023-1 | 2 | 30μ | 500n | 40k | 1.45 | 132n |
| 18μ | 3 | 30 |
ADA4177-4 | 4 | 60μ | 1μ | 3.5M | 1.5 | 8n | 175n | 500μ | 10 | 30 |
ADA4807-1 | 1 | 125μ | 700n | 200M | 225 | 3.3n | 160n | 1m | 2.7 | 11 |
ADA4177-2 | 2 | 60μ | 1μ | 3.5M | 1.5 | 8n | 175n | 500μ | 10 | 30 |
ADA4084-1 | 1 | 100μ | 500n | 15.9M | 4.6 | 3.9n | 100n | 565μ | 3 | 30 |
ADA4610-4 | 4 | 400μ | 1μ | 16.3M | 25 | 7.3n | 450n | 1.6m | 10 | 36 |
LT6020 | 2 | 30μ | 200n | 400k | 5 | 50n | 1.1μ | 90μ | 3 | 30 |
LT6020-1 | 2 | 30μ | 200n | 400k | 5 | 50n | 1.1μ | 90μ | 3 | 30 |
ADA4077-1 | 1 | 35μ | 250n | 3.9M | 1 | 7n | 250n | 400μ | 5 | 30 |
ADA4084-4 | 4 | 100μ | 500n | 15.9M | 4.6 | 3.9n | 100n | 565μ | 3 | 30 |
